| ابعاد |
105×210×240
|
| وزن تقریبی |
1924 گرم
|
| پیوستگی |
(Accurac:y ±(1.5%rdg+3dgt, Measuring Ranges: 20/200/2000Ω Autoranging, Open Circuit Voltage: >6V, Short Circuit Current: >200mA DC
|
| امپدانس لوپ |
(Nominal Test Current: 25A (20Ω range) | 1.2A (200Ω range) | 1.2A (2000Ω range, (Test Period: 1/2 cycle (10ms, [Rated Voltage: 230V AC ±10% [50Hz, [Voltage Measuring Range: 100 – 400V AC [50Hz, Base Accuracy: 20Ω range | ±(2%rdg+2dgt) D-LOK OFF | ±(5%rdg+5dgt) D-LOK ON, Impedance Ranges: 20/200/2000Ω
|
| (RCD (Uc |
__
|
| PSC (L-N / L-L) / PFC (L-PE) |
[Rated Voltage: 230V AC ±10% [50Hz, Accuracy: PSC accuracy derived from measured | loop impedance specification and measured | voltage specification, PSC Ranges: 2000A and 20kA
|
| RCD |
(Accuracy: Trip current +10%-0% of test current at 230V Trip time, ±(2%rdg + 3dgt, [Rated Voltage: 230V AC ±10% [50Hz, Trip Current Duration: RCD × 1/2 × 1: 2000ms | RCD × 5: 200ms fast trip 50ms, Trip Current Settings: RCD × 1/2 : 10,30,100,300,500,1000mA | RCD × 1 : 10,30,100,300,500,1000mA | RCD × 5 : 10,30,100mA
|
| Earth |
(Accuracy: 20Ω ±(2%rdg+5dgt) | 200/2000Ω ±(2%rdg+3dgt, Frequency: 720Hz ±5%, Output Voltage: 50V peak to peak square wave, Ranges: 20Ω/200Ω/2000Ω
|
| Phase Rotation |
_
|
| Volts |
_
|
| منبع تغذیه |
8 × 1.5V R6 or LR6
|
| استاندارد های مناسب |
IEC 61010-1 | CAT III 300V pollution degree 2
|
| تجهیزات و اقلام همراه |
(KSLP5 (external earth probe, 7025 (Lead for insulation and continuity testing), 7098 (Distribution board test leads for Loop/PSC/RCD testing ), 7099 (Moulded plug test leads(1 set) for Loop and RCD testing at sockets(EU plug), 7109 (Earth resistance test leads (1 set), 8032 (Auxiliary earth spikes), 8210 (IrDA Adaptor), Durable Holdall | Accessory pouch | Battery 8 × 1.5V R6 or LR6 | Instruction Manual
|
|
